Description
The arming vanes are anemometer type mounted perpendicular to the fuze axis on a special bracket using a flexible shaft to couple to the fuze arming stem.
Modification of Fuze M163 using the arming head of Tall Fuze AN-M100A2.
Functioning
No information about functioning.
Hazardous Components
No information about hazardous components.
See Also
Tail, Impact, AN-M100A1, AN-M100A2
Source(s)
MIL-HDBK-146, Fuze Catalog (1982)
